Specification
|
Unit
|
80T
|
125T
|
|
Nominal force
|
KN
|
800
|
1250
|
|
Stroke of slide
|
mm
|
140
|
160
|
|
Times of the slide stroke
|
times/min
|
60
|
50
|
|
Max closed height
|
mm
|
320
|
370
|
|
Closed height adjustment
|
mm
|
80
|
100
|
|
Throat Depth
|
mm*mm
|
300
|
360
|
|
Table size
|
mm
|
580*1000
|
700*1100
|
|
Motor power
|
KW
|
7.5
|
11
|
|
Overall size
|
mm
|
1780x1300x2780
|
1900x1300x3300
|
